Magnum Energy MS Series MS2012-GL 2kW 12VDC Pure Sine Wave Inverter / 100A PFC Charger w/ GFCI

Magnum Energy MS Series MS2012-GL 2kW 12VDC Pure Sine Wave Inverter / 100A PFC Charger w/ GFCI

Our Price: $2,163.72


Product Code: MS2012-GL
Qty:

Description Document(s)


Magnum Energy MS Series MS2012-GL 2kW 12VDC Pure Sine Wave Inverter / 100A PFC Charger w/ GFCI

Manufacturer Part#: MS2012-GL

The MS Series Inverter/Charger from Magnum Energy – a pure sine wave inverter designed specifically for the most demanding mobile, back-up, and off-grid applications. The MS Series is powerful, easy-to-use, and best of all, cost effective.

  • Power Factor Corrected (PFC) Charger - Our PFC charger is built into all of our inverter / chargers. It uses less energy from a generator than a standard charger, using 25-30% less AC current than standard chargers
  • Easy-To-Install - Install the MS Series in four easy steps: simply connect the inverter’s output to your distribution circuits or electrical panel, connect your utility power cable to the inverter’s easy-to-reach terminal block, connect the batteries, and switch on the power
Specifications

Full data sheet can be found in the Document(s) tab above.

Inverter Specifications
Input Battery Voltage Range 9 - 17 VDC
Nominal AC Output Voltage 120 VAC ± 5%
Output Frequency & Accuracy 60 Hz ± 0.1 Hz
Continuous Power Output At 25°C 2000 VA
Maximum Continuous Input Current 266 ADC
Inverter Efficiency (Peak) 89%
Charger Specifications
Continuous Output At 25°C 100 ADC
Charger Efficiency (Peak) 85%
Power Factor > .95
Input Current For Continuous Rated Output 15 AAC

Physical Specifications
Dimensions
(L x W x H)
34.9 x 32.1 x 17.8 cm
13.75 x 12.65 x 7.0 in
Weight 18.1 kg / 40 lbs
Shipping Weight 22.7 kg / 50 lbs
Max Operating Altitude 4,570 m (15,000 ft)
